Mindray uMEC12 patient monitor
The uMEC12 series patient monitors are designed to monitor, display, view, store and transmit various physiological parameters such as ECG, heart rate, respiration, temperature, arterial blood oxygen saturation, pulse rate, non-invasive blood pressure, invasive blood pressure, cardiac output and carbon dioxide. These monitors are intended for use in healthcare facilities by or under the supervision of healthcare professionals. Parameters may vary depending on the selected configuration.
Free shipping
Guarantee
Features
- Connection to the central monitoring station
- For uMEC12, the ECG monitoring function includes ECG monitoring in 3, 5 and 12-lead leads, ST segment analysis and arrhythmia analysis
- Storage compartment for accessories
- Quick access keys
- Connecting to Wi-Fi
- Complete with one or two lithium-ion batteries
- Can be equipped with an integrated thermographic printer
- Patient information can be entered using the on-screen keyboard
- Operating modes: monitoring mode, night mode, confidential mode, demonstration mode, standby mode
- Some operating modes can be password protected
- Automatic discharge of the patient after switching off the monitor
- Setting up the display of monitored parameters
- Set the colour of the numerical data and the curve for each measurement
- With the Auto Limits feature, the monitor can automatically adjust alarm limits according to measured vital signs
- After staying in the off state for a selected period of time, the monitor will automatically discharge the previous patient and register the new one when you start
- Transferring patient data using a USB stick
- Transfer data from a USB drive to a monitor
- Defibrillator synchronisation
Characteristics
- Display.: 12.1 inches, colour
- Dyslexia resolution: 800×600 pixels
- ECG monitoring: 3, 5, 12 leads
- Operating time on a single battery: ≥ 4 hours
- Mode of operation: continuous
- Degree of protection against dangerous water ingress: IPX1 (protection against vertically falling water droplets)
- Weight: 4 kg
- USB port: 2
- RJ45 port: 1
- VGA port: 1
- Temperature monitoring: Yes
- SpO2 monitoring: Yes
- CO2 monitoring: Yes
- NIAT monitoring: Optional
- IAT monitoring: Optional
- Monitoring of cardiac output: Optional
- AG monitoring: No.
- Monitoring of the ECG: No.
- BIS monitoring: No.
- Monitoring of mechanical respiratory parameters: No.
- Monitoring of continuous cardiac output: No.
- Monitoring of central venous blood oxygen saturation (ScvO2): No.
- Electroencephalogram (EEG): No.
- Monitoring of neuromuscular transmission (NMT): No.
- Monitoring of regional oxygen saturation (rSO2): No.
